NCM Aspen Plus

With a large tire width, the NCM Aspen + is hugely capable. Developed in Iceland for riding on snow and ice the Fat bikes large tires surface area make it great for soft terrain including sand and gravel. This E-bike is designed with a tough aluminium frame, and a strong rigid handlebar and saddle for improved ergonomics and performance. The high top tube, makes the bike sturdy and strong allowing the power you put down to be effectively transferred to the road.



BIKE COMPONENTS

Frame: Alu. 6061, 26"*18.9 inches

Suspension Fork: RST, Guid-TNL-26, Alu.

Brake: F/R: Tektro Hydraulic Disc Brakes,HD-E350

Freewheel: 8 Speed, 11-32T, Sliver

Tire: CST, C1752, 26"*4.0, Black

Saddle: Selle Royal, LOOKIN, Black

Stem: Promax. Alu.MA-471, Ext 90mm

Crank: Shimano, Acrea, 28/38/48T

Shifter: Shiamno,Altus, F: M315-L, 3-Speed; R: M315-8R, 8-Speed

Front Derailleur: Shimano, Altus, M310, 3-Speed

Rear Derailleur: Shimano, Acera, M360, 8-Speed



ELECTRIC COMPONENTS

Battery: Das-Kit, i5-4816, 48V 16AH, 768WH

Motor: Das-Kit, X15-fat, Rear drive motor, 48V 250W, 25KM/H

Controller: Das-Kit, CT5-I5, 48V 18A

Charger: 48V 3A, US standard

Display: Das-Kit, C7, 6 Levels

Front Light: Cateye, Front reflector

Rear Light: Cateye, Rear reflector





WEIGHT

Net Weight (with battery): 30.0kg

Battery Weight: 4.0kg

Max Load (driver+bike): 125.0kg
